Image preview - the first page of the document



>> Download CB6A documenatation <<

Text preview - extract from the document

                  EMI SUPPRESSORS
FEATURES

l Six hole beads, is available as beads and wound with tinned copper wire in several winding
  configurations.
l Compact; Easy installation.
l Employ high-performance ferrites with superior frequency characteristics.

APPLICATIONS

l Measures against radiated noise from personal computers, microcomputers, peripherals and
  related devices.
l Prevent intrusion of unnecessary signals and radiated emission noise into various interfaces.

                Model                                              Dimensions (mm)
CB6A




ORDERING CODE

  CB6A - 150            A : Model (Packing in Bulk)
   A      B             B : Number of turns


            Specification table of EMI Suppressors CB6A series
                       Impedance                                           Dimensions (mm)
           Sample                        Ferrite
  Model              |Z|( ) at 23                          Turns
             No.                         Material
