Image preview - the first page of the document
>> Download CCSP documenatation <<
Text preview - extract from the document
WIRE WOUND CHIP INDUCTORS
FEATURES MODEL
l High Self-Resonance Frequency l CCSP 0805 F
l Stable inductance at high frequency
l Tight inductance tolerance l CCSP 0805 C
l High Q factory l CCSP 0603 C
l High current l CCFH 0805 C
l Low DCR l CCFH 0603 C
l HCFT 0402 C
APPLICATIONS
l Antenna amplifiers
l Mobile phone
l Key entry
l GPS (Global Positioning System)
l Wireless LAN
l PDA (Personal Digital Assistant)
How to Specify Chip Inductor
C C S P 0 6 0 3 C 2 N 7 J
Bobbin type C U shape
H H shape
Bobbin material C Ceramic Bobbin
F Ferrite Bobbin
Electrode sort S Tin-Lead
F Pb Free
Wire sort P General Wire
S Soft Wire
D UEW-D
H HSEW
T Special Wire
Bobin size 0402,0603,0805
CEC'S CODE (Controlled by CEC)
Inductance e.g. 2N72.7nH
R39390nH
Inductance tolerance F G J K M X Y
