EMI SUPPRESSORS
FEATURES
l Use of high loss ferrite material.
l Easy mounting on PC boards.
l Available in a wide range of values and configurations to suit most of the applications.
APPLICATIONS
l Waveform correction of digital signals from digital applications
l Absorption of high-frequency noise from data lines.
Model Dimensions (mm)
RD28
Specification table of EMI Suppressors RD28
Impedance Rated Dimensions (mm)
Ferrite
Model No Sample No. IZI() at 23 Current
Material A B C D H
100MHz type (A)
RD28-5 854706 123 7 EL5 8.5 5 2.3 0.6 6max
854708 133 7 EL5
RD28-6 8.5 6 2.3 0.6 7max
854709 125 7 EL5
RD28-8 854710 175 7 EL6E 8.5 8 2.3 0.6 9max
Test Instrument: HP-4191A or HP-4395A
Specifications other than the above will be furnished upon request.
63
EMI SUPPRESSORS
IMPEDANCE Vs FREQUENCY CHARACTERISTICS OF RD28
TYPICAL ELECTRICAL CHARACTERISTICS
|Z| , R, X VS. FREQUENCY CHARACTERISTICS
Specifications other than the above will be furnished upon request.
64
