Image preview - the first page of the document



>> Download TOROID documenatation <<

Text preview - extract from the document

                  TOROID COILS
FEATURES
 l Enables you to make compact dummy choke coils for greater efficiency.
 l Less power loss and minimum thermal effect to peripheral components.
 l Perfectly matched to power supplies where average power and peak power differ greatly, with
    magnetic saturation kept minimum.
 l Low radiation noise based on its toroidal construction.
 l Various materials can meet with a wide range of frequency requirement.

APPLICATIONS
l Computers, Power supply, EMI/RFI Suppression and Wideband choke coils.

             MODEL                                     DIMENSION (mm)
RB54




RBPF




T251015B08




T381121B07-1




RB (with base)




                                              197
                  TOROID COILS
              MODEL                                      DIMENSIONS (mm)
RI




RI38




RIXG




RI50




RIC7




RI194




      Specifications other than the above will be furnished upon request.


                                               198
                   TOROID COILS
FEATURES

l    Use of high loss ferrite materials for excellent high frequency noise absorption.
l    High impedance for normal mode applications.
l    Enable common-mode noise suppression without interfering video signal.
l    This available in taping for automatic insertion.


APPLICATIONS

l   Absorption of high frequency noise from digital equipment data lines.
l   Countermeasures against radiated noise in personal computers, word processors etc.
l   Countermeasures against output noise of switching power supplies and switching AC adapters.
l   Countermeasures against common-mode noise at Composite video signals.

                  MODEL                                        DIMENSION (mm)
     RM77




                         Specification Table of Toroid of RM77
                                    Impedance
                   Inductance(H) |Z|( ) at 23 Rated current Dc resistance                Wire
                                                               (m) typ. Material
    Model No.                                                                                    Turns
                   (1kHz/5mA) typ. 100MHz typ.  (mA) typ.                                (mm)

RM77--854712
                         5             320          2600            18                           6
