Image preview - the first page of the document
>> Download CEC Series Table documenatation <<
Text preview - extract from the document
Series Table
Load Life Operating
Rated
Color of
Series Features Voltage Temp
Sleeve
1000hrs 2000hrs (V.DC) Range
Black
85 7mm Mini Size
TUK 6.3~63V -40~+85
Standard Blue
105 7mm Mini Size
TUM Black 6.3~63V -40~+105
Standard
Sapphire
TUN 85 General Standard 6.3~450V -40~+85
Blue
TUA 85 General Standard Purple 6.3~450V -40~+85
TUR 105 General Standard Black 6.3~450V -40~+105
105 High Frequency
6.3~16V
And
TUL Coffee -40~+105
25~50V
Low Impedance
TNP 85 Nonpolar Green 6.3~100V -40~+85
16~100V -40~+85
85 Lug/Snap-In
TUS Black
Terminal
160~450V -25~+85
16~100V -40~+105
105 Lug/Snap-In
TUF Black
Terminal
160~450V -25~+105
When you place an order of aluminum electrolytic capacitors. Please observe following catalog part
number, indication which designate our product.
