Image preview - the first page of the document
>> Download Cosonic Full documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR
INDEX
Leads W. V. (DC) Capacitance Operating Sleeve
Type Feature Load Life Page
Type Range Range (F) Temperature Color
FOR GENERAL USE
R Radial Miniature Standard Size 6.3V~ 100V 0.1~ 10,000 -40~ +85 1000 hr at 85 Blue EC-3
RM Radial Can Size 8x12mm, L.S. 5mm 6.3V~ 100V 10~ 470 -40~ +85 1000 hr at 85 Blue EC-6
RS Radial Subminiature Size, 7mm Height 6.3V~ 63V 0.1~ 220 -40~ +85 1000 hr at 85 Blue EC-8
SS Radial Subminiature Size, 5mm Height 4V~ 63V 0.1~ 47 -40~ +85 1000 hr at 85 Blue EC-10
RH Radial High Voltage 160V~ 450V 0.47~ 330 -25~ +85 1000 hr at 85 Blue EC-12
T Axial Miniature Standard Size 6.3V~ 100V 0.47~ 10,000 -40~ +85 1000 hr at 85 Blue EC-14
TH Axial High Voltage 160V~ 450V 1.0~ 330 -25~ +85 1000 hr at 85 Blue EC-16
LOW LEAKAGE CURRENT TYPE
RL Radial Miniature Standard Size 6.3V~ 63V 0.1~ 1,000 -40~ +85 1000 hr at 85 Orange EC-18
RSL Radial Subminiature Size 6.3V~ 63V 0.1~ 220 -40~ +85 1000 hr at 85 Orange EC-20
TL Axial Miniature Standard Size 6.3V~ 63V 0.47~ 1,000 -40~ +85 1000 hr at 85 Orange EC-22
FOR HIGH TEMPERATURE USE *D Blue: Dark Blue
RT Radial Miniature Standard Size 6.3V~ 100V 0.47~ 10,000 -40~ +105 1000 hr at 105 D Blue* EC-24
RST Radial Subminiature Size 6.3V~ 63V 0.1~ 220 -40~ +105 1000 hr at 105 D Blue EC-26
RHT Radial Miniature, High Voltage 160V~400V 0.47~1,000 -40~ +105 1000 hr at 105 D Blue EC-28
TT Axial Miniature Standard Size 6.3V~ 100V 0.47~ 4,700 -40~ +105 1000 hr at 105 D Blue EC-30
FOR LONG LIFE USE
RF Radial Miniature Standard Size 6.3V~ 100V 0.1~ 10,000 -40~ +85 2000 hr at 85 D Blue EC-3
RSF Radial Subminiature Size, 7mm Height 6.3V~ 100V 0.1~ 220 -40~ +85 2000 hr at 85 D Blue EC-8
TF Axial Miniature Standard Size 6.3V~ 100V 0.47~ 10,000 -40~ +85 2000 hr at 85 D Blue EC-14
NON-POLARIZED
RN Radial For Reversing Polarity Circuits 6.3V~ 100V 0.47~ 2,200 -40~ +85 1000 hr at 85 Violet EC-32
TN Axial For Reversing Polarity Circuits 6.3V~ 100V 0.47~ 1,000 -40~ +85 1000 hr at 85 Violet EC-34
For Horizontal Deflection 25V~ 50V 2.2~ 22 -25~ +85 1000 hr at 85 Violet
RP Radial EC-36
Equalization
For Crossover Network, 50V~ 100V 1.0~ 220 -40~ +85 1000 hr at 85 Violet
RB Radial EC-38
D.F.=12%
Axial For Crossover Network, 50V~ 100V 1.0~ 220 -40~ +85 1000 hr at 85 Violet
TB EC-38
D.F.=12%
SPECIAL TYPE
RE Radial Low ESR, High Ripple Current 6.3V~ 100V 1.0 ~ 1,000 -40~ +105 1000 hr at 105 Green EC-40
RI Radial Low Impedance, High R. C. 10v~ 100V 100 ~ 4,700 -55~ +105 2000 hr at 105 Green EC-43
RX Radial Miniature, Low ESR, High R.C. 6.3V~ 63V 1.0 ~ 4,700 -55~ +105 2000 hr at 105 Green EC-45
SURFACE MOUNT TYPE
V For 85 2000 hours 6.3V~ 100V 10~ 1,000 -40~ +85 2000 hr at 85 EC-48
V2 85 2000hr 5.5mm height 4V~ 50V 0.1~ 220 -40~ +85 2000 hr at 85 EC-50
V3 85 2000hr 5.5mm, 8mm height 6.3V~ 50V 4.7~ 330 -40~ +85 2000 hr at 85 EC-52
VS 105 1000hr 5.5mm height 6.3V~ 50V 0.1~ 100 -55~ +105 1000 hr at 105 EC-54
VL 105 2000hr 6mm height 6.3V~ 50V 0.1~ 100 -55~ +105 2000 hr at 105 EC-56
VB For Reversing Polarity Circuits 6.3V~ 50V 0.1~ 47 -40~ +85 2000 hr at 85 EC-58
VJ 105 2000hr 6.3V~ 100V 10~ 470 -55~ +105 2000 hr at 105 EC-60
VH 105 2000hr low impedance 6.3V~ 35V 47~ 1,000 -55~ +105 2000 hr at 105 EC-62
VZ 105 1000hr low impedance 6.3V~ 35V 4.7~ 220 -55~ +105 1000 hr at 105 EC-64
EC-1
ALUMINUM ELECTROLYTIC CAPACITOR
INDEX
Leads W. V. (DC) Capacitance Operating Sleeve
Type Feature Load Life Page
Type Range Range (F) Temperature Color
LARGE CAN TYPE
Large Capacitance, with Radial
LP Radial 10V~ 250V 220~ 22,000 -40~ +85 1000 hr at 85 Black EC-68
Auxiliary Lead
Large Capacitance, with Snap-in
LS Radial 10v~ 450V 47~ 22,000 -40~ +85 1000 hr at 85 Black EC-70
Terminal
Large Capacitance, Snap-in
LST Radial 16V~ 400V 47 ~ 15,000 -40~ +105 500 hr at 105 Black EC-75
Terminal
Large Capacitance, with Screw
LN Radial 6.3V~ 450V 270~ 18,000 -40~ +85 2000 hr at 85 Black EC-79
Terminal
DATA OF LEADS CUT, FORMING, TAPING, FLOW CHART
V Taping Specification for Surface Mount Type EC-66
Radial Cut and Forming EC-85
Radial Formed Leads for taping EC-86
Radial Tape and Reel EC-87
Axial Tape and Reel EC-88
Production & QC Inspection Flow Chart EC-89
PART NUMBER DESCRIPTION (for order booking)
Type Rated Cap. Cap. Tol. Rated Voltage DxL Lead Form & Package
(1) (2) (3) (4) (5) (6)
Example: RL 4.7 M 50V 5 X 11 TR
Tape & Reel
Case Size 5x11mm
50V DC
