Image preview - the first page of the document
Cosonic [radial thru-hole] RS-RSF Series


>> Download Cosonic [radial thru-hole] RS-RSF Series documenatation <<

Text preview - extract from the document
         ALUMINUM ELECTROLYTIC CAPACITOR

TYPE RS, RSF
SUBMINIATURE SIZE 7MM HEIGHT, RADIAL LEADS


FEATURES:
7mm height Subminiature standard size
Type RS -- Subminiature size, suitable for large capacitance
           in compact circuits.
Type RSF -- Subminiature size with longer load life


SPECIFICATIONS:
                 Item                              Type RS                                    Type RSF
Life (at 85)                                   1000 Hours                                    2000 Hours
Operating Temperature Range                                         -40 to +85
Capacitance tolerance
