Image preview - the first page of the document
>> Download ec04 documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR
TYPE R, RF
MINIATURE STANDARD SIZE FOR GENERAL USE, RADIAL LEAD
Dimensions in mm
D 5 6.3 8 10 13 16 18 22
F 2.0 2.5 3.5 5.0 5.0 7.5 7.5 10
d 0.5 0.5 0.5 0.6 0.6 0.8 0.8 0.8
CASE SIZE (DxL mm) AND PERMISSIBLE RIPPLE CURRENT (mA rms, at 85 120 Hz):
W.V. 6.3V 10V 16V 25V 35V 50V 63V 100V
F DxL R.C. DxL R.C. DxL R.C. DxL R.C. DxL R.C. DxL R.C. DxL R.C. DxL R.C.
0.1 5x11 1.5 5x11 3.0 5x11 3.0
0.22 5x11 3.5 5x11 4.5 5x11 4.5
0.33 5x11 5 5x11 7.5 5x11 7.5
0.47 5x11 6 5x11 9 5x11 9
1.0 5x11 10 5x11 15 5x11 15
2.2 5x11 19 5x11 30 5x11 30
3.3 5x11 30 5x11 38 5x11 38
4.7 5x11 41 5x11 43 5x11 46
10 5x11 50 5x11 54 5x11 60 5x11 63 6.3x11 74
22 5x11 70 5x11 75 5x11 80 5x11 90 5x11 90 6.3x11 125
33 5x11 87 5x11 92 5x11 100 6.3x11 120 6.3x11 130 8x12 180
47 5x11 92 5x11 105 5x11 110 6.3x11 130 6.3x11 140 8x11 170 10x12 225
100 5x11 125 5x11 135 5x11 150 6.3x11 180 8x11 220 8x11 240 10x12 260 10x21 360
220 5x12 170 5x12 200 6.3x11 260 8x11 300 8x12 370 10x12 423 10X16 470 13x26 600
330 6.3x11 260 6.3x11 305 8x11 345 8x14 400 10x12 500 10x16 595 10x21 620 13x26 760
470 6.3X12 315 8x11 365 8x12 428 10x12 520 10x21 650 10x21 710 13x21 820 16x25 990
1000 8X11 510 8x14 610 10x16 750 10x21 870 13x21 970 13x26 1110 16x25 1300 18x40 1380
2200 10X15 920 10x17 1045 13x21 1060 13x26 1250 16x26 1500 16x32 1790 18x40 2110
3300 10X21 1140 13x21 1230 13x26 1450 16x26 1690 18x32 1950 18x36 2220 22x43 2554
4700 13X21 1460 13x26 1520 16x26 1700 18x32 2040 18x36 2280 22x40 2865
10000 16X25 2037 18x32 2260 18x36 2360
issue: S EC-4
