Image preview - the first page of the document



>> Download ec33 documenatation <<

Text preview - extract from the document

            ALUMINUM ELECTROLYTIC CAPACITOR

TYPE RN
NON-POLARIZED FOR REVERSING POLARITY CIRCUITS, RADIAL LEADS




                                                                                                                Dimension in mm
                                                                                      D          5      6.3     8     10    13      16
                                                                                       F         2.0    2.5   3.5     5      5      7.5
                                                                                      d          0.5    0.5   0.5    0.6    0.6     0.8



CASE SIZE (DxL mm) AND PERMISSIBLE RIPPLE CURRENT (mA rms, at 85 120 Hz):
W.V.         6.3V            10V            16V            25V            35V              50V                63V             100V
 F         DxL    R.C.    DxL    R.C.    DxL      R.C.   DxL     R.C.   DxL R.C.      DxL        R.C.    DxL        R.C.    DxL     R.C.
 0.47                                                                                5x11        11      5x11       12     5x11      13
 1.0                                                                                 5x11        16      5x11       18     5x11      19
 2.2                                                                                 5x11        25      5x11       27     6.3x11    30
 3.3                                                                                 5x11        27      5x11       28     6x11      39
 4.7                                                     5x11    30     5x11    34   5x11        34     6.3x11      34     6x11      47
 10                                      5x11     44     5x11    42     5x11    43   6.3x11      52      6x11       57     8x12      71
 22        5x11     50    5x11     60    5x11     57     6x11    65     6x11    73   8x11        89      8x12       95     10x16     135
 33        5x11     70    5x11     64    5x11     60     6x11    80     8x12   100   8x12        105    10x12       135    13x21     190
 47        5x11     80    5x11     76    6x11     95     6x11    95     8x12   120   10x12       150    10x16       180    13x20     230
 100    6.3x11 125        6x11     125   8x12     160    8x12    160 10x16 230       10x20       265    13x20       320    16x26     370
 220       8x11     215   8x12     215   10x12    275 10x16      305 13x21 420       13x25       480    16x25       540
 330       8x12     265 10x12      340   10x16    375 13x20      450 13x20 505       16x25       650
 470    10x12       350 10x16      410   10x20    485 13x20      540 13x25 655
1000    10x20       550 13x21      700   16x26    850
2200    13x26 1040 16x25 1180




issue: R                                                        EC-33
