Image preview - the first page of the document
>> Download ec69 documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR
TYPE LP
LARGE CAPACITANCE, RADIAL AUXILIARY LEAD
Dimensions in mm
D 22 25
d 1.0 1.0
F1 10.0 12.5
F2 5.0 6.25
CASE SIZE (DxL mm):
WV F 10V 16V 25V 35V 50V 63V 80V 100V 160V 200V 250V
220 22X30 22X30 22X35
330 22X30 22X40 22X45
470 22X40 22X45 25X45
680 22X50 25X50
1000 22X30 22X35 22X35
2200 22X30 22X35 25X50 25X50
3300 22X30 22X40 22X50
4700 22X30 22X35 25X35 22X45 25X50
6800 22X30 22X40 25X45 25X50
10000 22X40 22X40 22X50 25X50
15000 22X40 22X50 25X50
22000 22X50 25X50
PERMISSIBLE RIPPLE CURRENT (A rms) at 120Hz, +85
WV F 10V 16V 25V 35V 50V 63V 80V 100V 160V 200V 250V
220 0.26 0.26 0.26
330 0.38 0.44 0.45
470 0.54 0.56 0.60
680 0.67 0.74
1000 0.73 0.82 0.85
2200 1.10 1.10 1.40 1.50
3300 1.40 1.50 1.60
4700 1.30 1.40 1.80 1.90 2.00
6800 1.70 1.80 2.30 2.40
10000 1.70 2.20 2.30 3.00
15000 2.40 3.10 3.30
22000 3.10 3.60
EC-69
