Image preview - the first page of the document
>> Download ec72 documenatation <<
Text preview - extract from the document
ALUMINUM ELECTROLYTIC CAPACITOR
TYPE LS -- LARGE CAPACITANCE WITH SNAP-IN TERMINAL
CASE SIZE (DxL mm), PERMISSIBLE RIPPLE CURRENT (A rms, at 120 Hz, 85)
& MAX E.S.R. (at 120 Hz, 20): for W.V. 50V~160V
W.V. 50V 63V 100V 160V
F DxL R.C. E.S.R. DxL R.C. E.S.R. DxL R.C. E.S.R. DxL R.C. E.S.R.
330 22x25 1.11 1.005
25x25 1.14 1.005
470 22x35 1.53 0.705
30x25 1.45 0.705
560 22x35 1.67 0.592
30x25 1.58 0.592
680 22x40 1.95 0.488
30x30 1.87 0.488
820 22x30 1.55 0.404 22x50 2.36 0.404
25x25 1.54 0.404 30x30 2.05 0.404
1000 22x25 1.42 0.414 22x30 1.71 0.332 25x45 2.55 0.332
25x25 1.46 0.414 30x25 2.20 0.332 35x30 2.62 0.332
1500 22x25 1.74 0.276 22x40 2.38 0.276 30x45 3.28 0.221
30x25 1.81 0.276 35x30 2.54 0.276
2200 22x25 1.92 0.226 22x30 2.08 0.226 25x45 2.77 0.188
25x25 1.98 0.226 30x25 2.10 0.226 35x30 3.07 0.188
3300 22x35 2.51 0.151 22x45 2.81 0.151 30x45 3.27 0.126
30x25 2.38 0.151 35x25 2.76 0.151
4700 22x40 2.89 0.106 25x45 3.11 0.106
35x25 2.99 0.106 35x30 3.20 0.106
6800 25x45 3.37 0.073 30x45 3.54 0.073
35x30 3.46 0.073
8200 25x50 3.62 0.061
35x35 3.79 0.061
10000 30x45 3.72 0.050
EC-72
