Image preview - the first page of the document



>> Download ec73 documenatation <<

Text preview - extract from the document

        ALUMINUM ELECTROLYTIC CAPACITOR

TYPE LS -- LARGE CAPACITANCE WITH SNAP-IN TERMINAL

CASE SIZE (D x L mm), PERMISSIBLE RIPPLE CURRENT (A rms, at 120 Hz, 85)
& MAX E.S.R. (at 120 Hz, 20): for W.V. 200V~450V
 W.V.           200V                    250V                    350V                    400V
 F      DxL     R.C.   E.S.R.   DxL     R.C.   E.S.R.   DxL     R.C.   E.S.R.    DxL    R.C.   E.S.R.
  47                                                                            22x25   0.43   8.818
                                                                                25x25   0.45   8.818
 100                                                    22x30   0.66   4.145    22x30   0.68   4.145
                                                        25x25   0.63   4.145    25x25   0.65   4.145
 150                                                    22x35   0.86   2.763    22x40   0.95   2.763
                                                        30x25   0.82   2.763    30x25   0.85   2.763
 220    22x25   0.97   1.507    22x30   1.14   1.507    22x45   1.17   1.884    22x50   1.27   1.884
        25x25   1.00   1.507    25x25   1.09   1.507    30x30   1.06   1.884    30x35   1.17   1.884
 330    22x30   1.29   1.005    22x40   1.58   1.005    25x50   1.53   1.256    30x45   1.59   1.256
        25x25   1.23   1.005    30x25   1.42   1.005    35x35   1.60   1.256    35x35   1.65   1.256
 470    22x40   1.74   0.705    22x50   2.09   0.705    30x50   1.92   0.882    35x45   2.19   0.882
        30x25   1.55   0.705    30x35   1.93   0.705    35x40   2.01   0.882
 560    22x45   2.00   0.592    25x45   2.29   0.592    35x45   2.31   0.740
        30x30   1.82   0.592    35x30   2.22   0.592
 680    25x40   2.14   0.488    30x40   2.45   0.488
        30x35   2.14   0.488    35x35   2.68   0.488
 820    25x50   2.59   0.404    30x45   2.83   0.404
        35x30   2.55   0.404    35x40   3.11   0.404
 1000   30x45   2.87   0.332    35x45   3.60   0.332
        35x35   2.99   0.332
 1500   35x50   4.24   0.221



 WV             450V
 F       DxL    R.C.   E.S.R.
 47     22x25   0.36   8.818
        25x25   0.37   8.818
 100    22x35   0.61   4.145
        25x30   0.59   4.145
 150    22x50   0.88   2.763
        30x30   0.76   2.763
 220    25x50   1.06   1.884
        35x35   1.13   1.884
 330    35x45   1.53   1.256




                                               EC-73
