Image preview - the first page of the document



>> Download ec81 documenatation <<

Text preview - extract from the document

           ALUMINUM ELECTROLYTIC CAPACITOR
RADIAL LEADS TAPE AND REEL
TAPING SPECIFICATIONS
This specification covers taped single ended electrolytic capacitors with body diameters
of 4, 5, 6, 8 , 10 or 13 mm
1. Polarity of capacitors shall be oriented in one direction.
2. Up to 3 capacitors consecutively missing on tape is permitted, but a designated quantity of capacitors
   shall be packed in each case.
3. Removal of faulty capacitors from the tape shall be by pulling out or by cutting off leads. Cut off leads
   remaining on tape shall not protrude more than 2mm max. from tape edge.




DIMENSIONS (mm):
                                                                             BODY DIA.
                  ITEM                    SYMBOL         4, 5, 6.3MM     8MM        10 MM          13MM          TOLERANCE
   Body Height                               L               12.5        17.0        17.0     21.5, 26.5, 31.5      max.
   Pitch of component                       P                12.7        12.7        12.7           15.0
