Image preview - the first page of the document
UCC [radial thru-hole] KZJ series


>> Download UCC [radial thru-hole] KZJ series documenatation <<

Text preview - extract from the document
                                                NEW SERIES
                                           Engineering Bulletin Jul 03


KZJ Series

  Miniature




                                                                                                                             MINIATURE -105 C
  Ultra Low




                                                                                                                                                KZJ
  Impedance
  Low Resistivity
  Electrolyte
   105 C
  Maximum
  Temperature                                               Actual
                                                            Size




The KZJ series is a new ultra low impedance series from United Chemi-Con. These capacitors are
different from the standard low impedance capacitors, as they use a new low resistivity electrolyte.
Compared to our KZG series that also uses this advanced electrolyte technology, the KZJ series has
lower ESR / impedance and higher ripple current capability, making them ideal for use in computer
motherboard circuits where very low impedance at high frequencies is required. This series offers
large capacitance per case size and a rated lifetime of 2,000 hours at 105 C with the rated ripple
current applied. As an option the KZJ series is available with environmentally friendly PET (polyester)
sleeves and Pb-free materials.
The KZJ series capacitors are non-solvent proof. Refer to the Mini-Glossary for cleaning guidelines
and recommended cleaning agents that are compatible with United Chemi-Con products.

                                  Summary of Specifications

       Radial lead terminals.
       Capacitance range: 470 to 3,300
