Image preview - the first page of the document



>> Download Chirx [bi-polar axial] CD72H Series documenatation <<

Text preview - extract from the document

CD72/CD72H SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 CD72: Load life of 1000 hours at 85
 CD72H: Load life of 1000 hours at 105
 Bi-polarized, low dissipation factor and excellent frequency
 Characteristics
 For speaker networks, Hi-Fi audio system
 SPECIFICATIONS
                 Item                                                        Characteristics
Operating Temperature Range()                                        -40~+85(CD72H: -40~+105)
Rated Voltage Range (V)                                                           50
Nominal capacitance range (F)                                                   1~100
Capacitance Tolerance(20,120Hz)                                     P grade:
