Image preview - the first page of the document



>> Download Chirx [bi-polar radial] CD71 Series documenatation <<

Text preview - extract from the document

CD71 SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 2000 hours at 85
 Bi-polarized standard
 Used in polarity reverses and change circuits
SPECIFICATIONS
               Item                                                                         Characteristics
Operating Temperature Range()                                                                     -40~+85
Rated Voltage Range (V)                                                                           6.3~160
Nominal capacitance range (F)                                                                     0.1~4700
Capacitance Tolerance(20,100Hz)
