Image preview - the first page of the document



>> Download Chirx [radial thru-hole] CD117H Series documenatation <<

Text preview - extract from the document

CD117/CD117H SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 CD117: Load life of 1000 hours at 85
 CD117H:Load life of 1000 hours at 105
 High stability, low dissipation factor, Low leakage current
 Used in high stability circuits.
 SPECIFICATIONS
                 Item                                                              Characteristics
Operating Temperature Range()                                                 -40~+85(CD117H: -40~+105)
Rated Voltage Range (V)                                                                   10~50
Nominal capacitance range (F)                                                            0.47~47
Capacitance Tolerance(20,120Hz)
