Image preview - the first page of the document



>> Download Chirx [radial thru-hole] CD110X Series documenatation <<

Text preview - extract from the document

CD110/CD110X SERIES
ALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 2000 hours at 85
 Small size, High stability and reliability
 For general consumer electronic products application

 SPECIFICATIONS
               Item                                                                            Characteristics

Operating Temperature Range()                                                                       -40~+85

Rated Voltage Range (V)                                                                             6.3~450

Nominal capacitance range (F)                                                                      0.1~22000

Capacitance Tolerance(20,120Hz)
