Image preview - the first page of the document



>> Download Chirx [radial thru-hole] CD113(H) Series documenatation <<

Text preview - extract from the document

CD113/CD113H SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 CD113: Load life of 1000 hours at 85
 CD113H:Load life of 1000 hours at 105
 Low dissipation factor, High stability
 SPECIFICATIONS
              Item                                                      Characteristics
Operating Temperature Range()                                   -40~+85(CD113H:-40~+105)
Rated Voltage Range (V)                                                      6.3~100
Nominal capacitance range (F)                                                0.1~4700
Capacitance Tolerance(20,120Hz)
