Image preview - the first page of the document
Chirx [radial thru-hole] CD269 Series

>> Download Chirx [radial thru-hole] CD269 Series documenatation <<

Text preview - extract from the document

 Load life of 2000 hours at 125
 Wide temperature, Long life
              Item                                                                     Characteristics
Operating Temperature Range()                                                             -40~+125
Rated Voltage Range (V)                                    10~63                                                    100~350
Nominal capacitance range (F)                             47~3300                                                  0.47~100
Capacitance Tolerance(20,120Hz)
