Image preview - the first page of the document



>> Download Chirx [radial thru-hole] CD288 Series documenatation <<

Text preview - extract from the document

CD288/CD288H SERIES
AALUMINUM ELECTROLYTIC CAPACITORSS

 Load life of 1000 hours at 85
 CD 288H: Load life of 1000 hours at 105
 High frequency and low impedance
 SPECIFICATIONS
               Item                                                    Characteristics
Operating Temperature Range()          -40~+85(CD288H: -40~+105)                                -25~+85(CD288H: -25~+105)
Rated Voltage Range (V)                           10~100                                                   160~250
Nominal capacitance range (F)                                                4.7~3300
Capacitance Tolerance(20,120Hz)
