Image preview - the first page of the document
Acon [SMD] RVH Series


>> Download Acon [SMD] RVH Series documenatation <<

Text preview - extract from the document
RVH series               125 Wide Temperature               125
Features
   Reflow soldering available for reflow soldering.
   Available for high density surface mounting.
   High stability and reliability.
   Lifetime: 125,1000 Hr.
Specifications
              Item                                                   Performance Characteristics
  Operating Temperature range
                                                                            -40+125
             Range
      Rated Voltage Range                                                   1050 VDC

   Nominal capacitance range                                                 10330F

  Nominal capacitance tolerance
