Image preview - the first page of the document



>> Download Acon [radial thru-hole] DKL Serie documenatation <<

Text preview - extract from the document

DKL series               Low Impedance                       Long Life Assurance
Features
 Low impedance for high frequency. Used in communication equipments ,
    switching power supply, industrial measuring instruments, etc.
 Endurance:4000 ~10000 hours at 105
 RoHs Compliant
Specifications
         Item                                                              Performance Characteristics
  Temperature Range                                                                      -40~+105
  Rate Voltage Range                                                                     6.3~100VDC
  Capacitance Range                                                                      10~4700F
 Capacitance Tolerance
