Image preview - the first page of the document



>> Download Acon [radial thru-hole] GFE Series documenatation <<

Text preview - extract from the document

GFE series             Low Impedance Wide Temperature
Features
 High temperature range, for +125 use.
 Highly dependable reliability withstanding load life of 2000 hours at +125
 Suited for automobile electronics where heavy duty services are indispensable
Specifications
         Item                                                          Performance Characteristics
 Temperature Range                                   -40~+125(10 to 250VDC)                 -25~+125(350 to 450VDC)
  Rate Voltage Range                                                               10~450VDC
  Capacitance Range                                                                1~4700F
Capacitance Tolerance
