Image preview - the first page of the document



>> Download Acon [radial thru-hole] GFW Series documenatation <<

Text preview - extract from the document

GFW series                Low Impedance               Wide Temperature
Features
 Wide temperature range: -55~+125.
 Endurance:3000 ~10000 hours at 105
 RoHs Compliant
Specifications
        Item                                                         Performance Characteristics
 Temperature Range                                                             -55~+125
  Rate Voltage Range                                                           6.3~50VDC
  Capacitance Range                                                            0.47~6800F
Capacitance Tolerance
