Image preview - the first page of the document
Acon [radial thru-hole] LED Series


>> Download Acon [radial thru-hole] LED Series documenatation <<

Text preview - extract from the document
LED series              Low Impedance For LED Light
Features
 Especially designed for LED light.
 Endurance:4000 ~10000 hours at 105
 RoHs Compliant
Specifications
         Item                                                           Performance Characteristics
  Temperature Range                                                                   -40~+105
  Rate Voltage Range                                                                  6.3~100VDC
  Capacitance Range                                                                   15~3900F
 Capacitance Tolerance
