Image preview - the first page of the document
Acon [radial thru-hole] LZ Series


>> Download Acon [radial thru-hole] LZ Series documenatation <<

Text preview - extract from the document
LZ series           Special Low Impedance
Features
 Load Life 2000~5000 hours at 105
 Lowest impedance for personal computer and storage equipment
 RoHs Compliant
Specifications
         Item                                                          Performance Characteristics
  Temperature Range                                                                  -40~+105
  Rate Voltage Range                                                                 6.3~25VDC
  Capacitance Range                                                                  100~3900F
 Capacitance Tolerance
