Image preview - the first page of the document
Acon [screw terminal] WL Series


>> Download Acon [screw terminal] WL Series documenatation <<

Text preview - extract from the document
WL Series              Screw Type105 Long Life

Features

 u High ripple currentLarge capacity
 u Load Life5000 hours at 105

Specifications
        Item                                                    Performance Characteristics
    Operating
                                                                         -25~+105
 Temperature Range
 Rate Voltage Range                                                       350~450V

 Capacitance Range                                                      1000~15000F
    Capacitance
