Image preview - the first page of the document
Acon [snap-in] FP Series


>> Download Acon [snap-in] FP Series documenatation <<

Text preview - extract from the document
FP Series           Snap-in Terminal Type105 Miniaturized
Features
 u Height 20mm
 u Load Life2000 hours at 105
 u Voltage range of 160~400V

Specifications
        Item                                                  Performance Characteristics
    Operating
                                                                      -25~+105
 Temperature Range
 Rate Voltage Range                                                    160~400V

 Capacitance Range                                                     47~680F
    Capacitance
