Image preview - the first page of the document



>> Download Acon [snap-in] HP Series documenatation <<

Text preview - extract from the document

HP Series           Snap-in Terminal Type105 Standard
Features
u High ripple currentsmaller size
u Load Life2000 hours at 105

Specifications
         Item                                                Performance Characteristics
 Operating Temperature
                                           -40~+105                                               -25~+105
         Range
   Rate Voltage Range                       10~100V                                               160~450V

   Capacitance Range                                                  56~82000F

 Capacitance Tolerance
