Image preview - the first page of the document



>> Download Acon [snap-in] KP Series documenatation <<

Text preview - extract from the document

KP Series              Snap-in Terminal Type105 Long Life
Features
 u High ripple currentsmaller size
 u Load Life5000 hours at 105
Specifications
        Item                                                   Performance Characteristics
    Operating
                                           -40~+105                                                -25~+105
 Temperature Range
 Rate Voltage Range                         10~100V                                                160~450V

 Capacitance Range                                                      56~56000F
