Image preview - the first page of the document



>> Download Acon [snap-in] SP Series documenatation <<

Text preview - extract from the document

SP Series          Snap-in Terminal            105 Long Life
Features
 u High ripple currentsmaller size
 u Load Life3000 hours at 105

Specifications
        Item                                                 Performance Characteristics
    Operating
                                         -40~+105                                                -25~+105
 Temperature Range
 Rate Voltage Range                       10~100V                                                160~450V

 Capacitance Range                                                    56~56000F
