Image preview - the first page of the document
>> Download Aillen Series Table documenatation <<
Text preview - extract from the document
LIST OF PRODUCTS
V uF
New product
Low Impedance
Ultra low Impedance
standard
Terminal Raged Nominal Operating
Low L.C
Long life
Series Feature Page
Type Voltage Capacitance Temperature
Range Range Range
CDV 85 5.5mm 5.5mm Height Chip 4~100 0.1~1500 -40~+85
CDVT 105 5.5mm 5.5mm Height Chip 4~100 0.1~1500 -40~+105
V-chip
CDVB 105 Bi-polarized Chip 6.3~100 0.1~47 -40~+105
CDVD 105 Low leakage current Chip 4~100 0.1~1000 -40~+105
CDVZ 105 Low Impedance Chip 4~50 0.1~1500 -40~+105
CD110 X 85 Standard Radial 6.3~450 0.1~10000 -40 -25 ~+85
CD11T 105 Standard Radial 6.3~100 0.1~10000 -40~+105
CDT 105 High Voltage Radial 160~450 0.47~330 -25~+105
CD11E 85 5.5mm 5.5mm Height Radial 4~50 0.1~330 -40~+85
CD11ET 105 5.5mm 5.5mm Height Radial 4~50 0.1~330 -40~+105
Standerdard
CD11C 85 7mm 7mm Height Radial 4~63 0.1~470 -40~+85
CD11CT 105 7mm 7mm Height Radial 4~63 0.1~330 -40~+105
CD117 85 High Stability Radial 16~50 1~470 -40~+85
CD11K 105 Wide Temperature Range Radial 6.3~100 0.1~4700 -55~+105
105
CD11V Radial 4~100 0.1~1500 -40~+105
Endure High Soldering Temperature
CD110H 85 Long Life Radial 6.3~450 0.1~10000 -40 -25 ~+85
105
Long Life
CDL Radial 6.3~100 15~10000 -40~+105
Low Working Voltage Long life
105
CDTA Radial 160~450 1~100 -25~+105
High Working Voltage Long life
105 5 Radial
CD11EZ 6.3~50 1~100 -40~+105
5mm Height Low Impedance
105 7 Radial
CD11CZ 6.3~50 4.7~220 -40~+105
7mm Height, Low Impedance
85 Radial
CD288 10~160 2.2~6800 -40 -25 ~+85
Low Impedance
High Frequency Low Impedance
105 Radial
CD288T 10~160 2.2~6800 -40 -25 ~+105
High Frequency Low Impedance
105 Radial
CD11Z 6.3~100 10~4700 -40~+105
Extermely Low Impedance
105 Radial
CD11ZL Extermely Low Impedance 6.3~100 10~4700 -40~+105
Long Life
CD11D 85 Low leakage current Radial 6.3~100 0.1~2200 -40~+85
85 5mm Radial
Low L.C
CD11ED 4~50 0.1~330 -40~+85
5mm Height Low Leakage Curren
85 7mm Radial
CD11CD 4~63 0.1~470 -40~+85
7mm Height Low Leakage Current
Low L.C
Long Life
85
CD11DH Radial 6.3~100 0.1~2200 -40~+85
Low leakage current Long life
CD71 85 Bi-polarized Radial 6.3~100 0.1~4700 -40~+85
105 Radial
CD71T 6.3~100 0.1~4700 -40~+105
Bi-polarized, High Temperature
85 5 Radial
CD71E 6.3~50 0.1~100 -40~+85
5.mm Height Bi-polarized
CD71ET 105 5mm Height Bi-polarized Radial 6.3~50 0.1~100 -40~+105
Bi-polarized
85 7 Radial
CD71C 6.3~50 0.1~100 -40~+85
7mm Height Bi-polarized
105 7 Radial
CD71CT 6.3~50 0.1~100 -40~+105
7mm Height Bi-polarized
85 Radial
CD71S 25~50 1~22 -40~+85
Horizontal Deflection Equalization
85 Radial
CD71A 50~100 0.47~33 -40~+85
For Audio Crossover Network, Bi-polar
CD293 85 High Ripple Current Snap-in 10~450 56~82000 -40 -25 ~+85
CD294 105 High Ripple Current Snap-in 16~450 47~47000 -40 -25 ~+105
85
CD295 Snap-in 16~450 47~47000 -40 -25 ~+85
High Ripple Current Long Life
105
CD296 Snap-in 16~450 47~47000 -40 -25 ~+105
Largesize
High Ripple Current Long Life
105
CD298 High Ripple Current Snap-in 400~450 39~470 -25~+105
Extermely Long Life
105
CD298A High Ripple Current Snap-in 400~450 39~470 -25~+105
Ultra Long Life
