Image preview - the first page of the document
Beryl [non-polar thru-hole] BP Series


>> Download Beryl [non-polar thru-hole] BP Series documenatation <<

Text preview - extract from the document
MINIATUREALUMINUMELECTROLYTICCAPACITORS                                                                    BERYL
BP Series
   85 Standard Bi-polarized type
   For horizontal deflection circuit.
   High ripple capability.
   RoHS Compliant
  SPECIFICATIONS
 Items                                                   Characteristics

Category                                                          -40 ~ +85
Temperture Range

                                                                   25 V,50V
Rated voltage Range
