                                          www.zq-beryl.com




MINIATUREALUMINUMELECTROLYTICCAPACITORS                                                         BERYL
BQ Series
 105 Standard Bi-polarized type
 For horizontal deflection circuit.

 High ripple capability.

 RoHS Compliant


  SPECIFICATIONS
     Items                                             Characteristics

Category                                                      -55 ~ +105
Temperture Range

                                                                 25 V,50V
Rated voltage Range
