MINIATUREALUMINUMELECTROLYTICCAPACITORS                                                                       BERYL
HD Series
 For electronic ballast circuits and other long life required applications
 Endurance with ripple current:105 8000 to 10000 hours
 RoHS Compliant
  SPECIFICATIONS
 Items                                                          Characteristics

Category                                               -40 ~ +105(160 ~ 400V)          -25 ~ +105(450V)
Temperture Range

                                                                           160 ~ 450V
Rated Voltage Range
