       Axial High Voltage 105

Features
 105   medium and high voltage capacitors.

                           ========== Missing Section ==========

    Diagram of Dimensions Lead                                                 Spacing and Diameter
    Internal Structure




                           Dimensions and Permissible Ripple Current
                                                                                                                        105

                                  160               200               250               350                400               450
                                 (200)             (250)             (300)             (400)              (450)             (500)

                              DXL        mA     DXL        mA     DXL        mA      DXL       mA      DXL        mA      DXL       mA


            1        010                                         6.3 x 12    12     8 x 13     13     8 x 13      13     8 x 13     13

           2.2       2R2                                         6.3 x 12    18     8 x 13     18    10 x 13.5    34    10 x 13.5   34

           3.3       3R3    6.3 x 12     27    6.3 x 12    27    8 x 13      31    10 x 13.5   34    10 x 13.5    34     10 x 17    38

           4.7       4R7     8 x 13      37    8 x 13      37    8 x 13      37    10 x 17     45    10 x 21      50     10 x 21    50

           10        100    10 x 13.5    65    10 x 17     65    10 x 17     73    10 x 21     74    13 x 22      75     13 x 22    75

           22        220     10 x 21     118   10 x 21     118   13 x 22     140   13 x 27     141   16 x 27      141    16 x 27    141

           33        330     10 x 21     145   13 x 22     171   13 x 27     188   16 x 27     193   16 x 32      189    16 x 33    189

           47        470     13 x 22     205   13 x 27     225   16 x 27     231   16 x 33     253   16 x 37      238    16 x 37    238

           100       101     16 x 22     337   16 x 32     369   16 x 37     426

           220       221     18 x 37     632   18 x 42     675

           330       331     18 x 42     826




                                       JEENN CHWANQ ENTERPRISE CO., LTD
                                       Aluminum Electrolytic Capacitors, since 1975
           11F-1, B, No.93, Tashun 1st Rd, Kaohsiung Taiwan TEL: 886-7-7319008 FAX: 886-7-7315732
                                       Email: [email protected]
