Image preview - the first page of the document
>> Download 17232913054d9b1a3e5ff1 documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS 200 to 450Vdc, Downsized, 105C
@Downsize, high ripple design (F10 to 18) PAG
@Rated voltage range : 200 to 450Vdc., Capacitance range : 18 to 560MF
@Endurance with ripple current : 2,000 hours at 105C Downsized
Higher ripple
@Ideal for low profile power supply applications
@Non solvent resistant type KMG
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +105C (200, 400Vdc) -25 to+105C (420, 450Vdc)
Rated Voltage Range 200 to 450Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current After 1 minute After 5 minutes
CV[1,000 I=0.1CV+40 I=0.03CV+15
CV>1,000 I=0.04CV+100 I=0.02CV+25
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C)
Dissipation Factor Rated voltage (Vdc) 200V 400V 420V 450V
(tanE) tanE (Max.) 0.12 0.15 0.20 0.20 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 200V 400V 420V 450V
Characteristics Z(-25C)/Z(+20C) 3 5 6 6
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 6 6 - - (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 2,000 hours at 105C.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [500% of the initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Brown)
FP0.5
FP0.5
Fd
f10 & f12.5 fD 10 12.5 14.5 16 18
fd 0.6 0.6 0.8 0.8 0.8
FD'
F 5.0 5.0 7.5 7.5 7.5
fD' FD+0.5 max.
Vent L' 15min. 4min. L' L+2.0 max.
(F10) (F12.5)
Gas escape end seal
Sleeve (PET : Brown)
FP0.5
Fd
]f14.5
FD'
Vent L' 15min. 4min. (F14.5 to F18)
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E P AG AAA E AA AAA M AAA S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 22MF:220,100MF:101)
