Image preview - the first page of the document
>> Download mva documenatation <<
Text preview - extract from the document
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS Downsized, 85C
@F4 through F18 case sizes are fully lined up MVA MVE
@Endurance : 2,000 hours at 85C 105C
@Suitable to fit for downsized equipment
@Solvent resistant type except 100 to 450Vdc (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +85C
Rated Voltage Range 4 to 450Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current Rated voltage (Vdc) 4 to 100V 160 to 450V
D55 to JA0 I=0.01CV or 3MA, whichever is greater.(after 2 minutes) -
KE0 to MN0 I=0.03CV or 4MA, whichever is greater.(after 1 minute) I=0.04CV+100MA max.(after 1 minute)
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C)
Dissipation Factor Rated voltage (Vdc) 4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
(tane) D55 to JA0 0.42 0.35 0.30 0.26 0.16 0.14 0.12 0.12 0.12 - -
tanE (Max.)
KE0 to MN0 - 0.38 0.34 0.30 0.26 0.22 0.18 0.14 0.10 0.20 0.25
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase. (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 4V 6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 400 & 450V
Characteristics Z(-25C)/Z(+20C) 7 4 3 2 2 2 2 2 3 - -
(Max. Impedance Ratio) D55 to JA0
Z(-40C)/Z(+20C) 17 10 8 6 4 3 3 3 4 - -
Z(-25C)/Z(+20C) - 5 4 3 2 2 2 2 2 3 6
KE0 to MN0
Z(-40C)/Z(+20C) - 12 10 8 5 4 3 3 3 6 10 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 2,000 hours
at 85C.
Size code D55 to JA0 D55 to JA0 KE0 to MN0
Rated voltage (Vdc) 4V & 6.3V 10 to 100V 6.3 to 450V
Capacitance change [P30% of the initial value [P20% of the initial value
DF (tanE) [200% of the initial specified value [200% of the initial specified value
Leakage current [The initial specified value [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 85C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Size code D55 to JA0 D55 to JA0 KE0 to MN0
Rated voltage 4V & 6.3V 10 to 100V 6.3 to 450V
Capacitance change [P30% of the initial value [P20% of the initial value
DF (tanE) [200% of the initial specified value [200% of the initial specified value
Leakage current [The initial specified value [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : A @Terminal Code : G Size code D L A B C W P
@Size code : D55 to MN0 @Size code : LH0 to MN0 D55 4 5.2 4.3 4.3 5.1 0.5 to 0.8 1.0
0.3max. W E55 5 5.2 5.3 5.3 5.9 0.5 to 0.8 1.4
W F55 6.3 5.2 6.6 6.6 7.2 0.5 to 0.8 1.9
F80 6.3 7.7 6.6 6.6 7.2 0.5 to 0.8 1.9
FDP0.5
CP0.2
HA0 8 10.0 8.3 8.3 9.0 0.7 to 1.1 3.1
BP0.2
FDP0.5
CP0.2
BP0.2
P
P
JA0 10 10.0 10.3 10.3 11.0 0.7 to 1.1 4.5
KE0 12.5 13.5 13.0 13.0 13.7 1.0 to 1.3 4.2
KG5 12.5 16.0 13.0 13.0 13.7 1.0 to 1.3 4.2
LH0 16 16.5 17.0 17.0 18.0 1.0 to 1.3 6.5
0.3max. AP0.2 LP0.5 AP0.2 LN0 16 21.5 17.0 17.0 18.0 1.0 to 1.3 6.5
LP0.3(Note) MH0 18 16.5 19.0 19.0 20.0 1.0 to 1.3 6.5
Note : LP0.5 for HA0 to MN0 : Dummy terminals MN0 18 21.5 19.0 19.0 20.0 1.0 to 1.3 6.5
?PART NUMBERING SYSTEM ?MARKING
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E MV A AAA A AA AAA M AAA N D55 to JA0 KE0 to HN0
EX) 16V47MF EX) 25V1,000MF
Supplement code 0V
7hA MVA
Size code
Capacitance tolerance code 47 1000
Capacitance code (ex. 1.0MF:1R0,100MF:101) 16V 25V
