Image preview - the first page of the document
>> Download mzf documenatation <<
Text preview - extract from the document
SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS Low impedance, 10000-hours-life, 105C
New!
@Endurance : 10,000 hours at 105C
@Low impedance
Longer life Longer life
@Rated voltage range : 6.3 to 50V MLA MZE MZF
@Nominal capacitance range : 10 to 470MF
@Suitable for high reliability products
@Solvent resistant type (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -25 to +105C
Rated Voltage Range 6.3 to 50Vdc
Capacitance Tolerance P20%(M) (at 20C,120Hz)
Leakage Current I=0.01CV or 3MA, whichever is greater
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C, after 2 minutes)
Dissipation Factor Rated voltage (Vdc) 6.3V 10V 16V 25V 35V 50V
(tane) tanE (Max.) 0.32 0.28 0.26 0.16 0.14 0.14 (at 20C,120Hz)
Low Temperature Rated voltage(Vdc) 6.3V 10V 16V 25V 35V 50V
Characteristics Z(-10C)/Z(+20C) 4 3 2 2 2 2
(Max. Impedance Ratio) (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 10,000 hours
at 105C.
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm] ?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
@Terminal Code : A E MZ F AAA A DA AAA M AAA G
W Supplement code
Size code
FDP0.5
CP0.2
BP0.2
Capacitance tolerance code
P
Capacitance code (ex. 47MF:470,100MF:101)
Taping code
Terminal code
0.3max. AP0.2 Voltage code (ex. 6.3V:6R3,10V:100,25V:250)
LP0.3 (Note) Series code
Note : LP0.5 for HA0 and JA0 Category
Please refer to "Product code guide (surface mount type)"
Size code D L A B C W P
E73 5 7.0 5.3 5.3 5.9 0.5 to 0.8 1.4
F73 6.3 7.0 6.6 6.6 7.2 0.5 to 0.8 1.9 ?MARKING
F90 6.3 8.7 6.6 6.6 7.2 0.5 to 0.8 1.9 EX) 16V47MF @Rated voltage symbol
HA0 8 10.0 8.3 8.3 9.0 0.7 to 1.1 3.1
4h Rated voltage (Vdc) 6.3 10 16 25 35 50
JA0 10 10.0 10.3 10.3 11.0 0.7 to 1.1 4.5
Symbol j A C E V H
47
C ZF
?STANDARD RATINGS
Rated ripple Rated ripple
Impedance Impedance
WV Cap current WV Cap current
Size code (omax/20c, Part No. Size code (omax/20c, Part No.
(Vdc) (mF) (mArms/105c, (Vdc) (mF) (mArms/105c,
100kHz) 100kHz)
100kHz) 100kHz)
47 E73 2.2 95 EMZF6R3ADA470ME73G 33 F73 1.1 140 EMZF250ADA330MF73G
100 F73 1.1 140 EMZF6R3ADA101MF73G 47 F73 1.1 140 EMZF250ADA470MF73G
6.3 220 F90 1.0 230 EMZF6R3ADA221MF90G 25 100 F90 1.0 230 EMZF250ADA101MF90G
330 F90 1.0 230 EMZF6R3ADA331MF90G 220 HA0 0.22 600 EMZF250ADA221MHA0G
470 HA0 0.22 600 EMZF6R3ADA471MHA0G 330 JA0 0.16 850 EMZF250ADA331MJA0G
33 E73 2.2 95 EMZF100ADA330ME73G 10 E73 2.2 95 EMZF350ADA100ME73G
10
150 F73 1.1 140 EMZF100ADA151MF73G 10 F73 1.1 140 EMZF350ADA100MF73G
22 E73 2.2 95 EMZF160ADA220ME73G 22 E73 2.2 95 EMZF350ADA220ME73G
47 F73 1.1 140 EMZF160ADA470MF73G 22 F73 1.1 140 EMZF350ADA220MF73G
35
100 F73 1.1 140 EMZF160ADA101MF73G 33 F90 1.0 230 EMZF350ADA330MF90G
16 150 F90 1.0 230 EMZF160ADA151MF90G 47 F90 1.0 230 EMZF350ADA470MF90G
220 F90 1.0 230 EMZF160ADA221MF90G 100 HA0 0.22 600 EMZF350ADA101MHA0G
330 HA0 0.22 600 EMZF160ADA331MHA0G 220 JA0 0.16 850 EMZF350ADA221MJA0G
470 JA0 0.16 850 EMZF160ADA471MJA0G 47 HA0 0.53 350 EMZF500ADA470MHA0G
50
25 22 E73 2.2 95 EMZF250ADA220ME73G 100 JA0 0.35 670 EMZF500ADA101MJA0G
(1/1) CAT. No. E1001K
