Image preview - the first page of the document
>> Download pxk documenatation <<
Text preview - extract from the document
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Surface Mount
New!
@Super low ESR, impedance and high heat resistance have been obtained by using
PXK
conductive polymer as electrolyte.
@Rated voltage range : 2.5 to 16Vdc, Capacitance range : 100 to 560MF Downsized
@Suitable for DC-DC converters, voltage regulators and decoupling applications used to
PXE
computer motherboards etc.
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -55 to +105C
Rated Voltage Range 2.5 to 16Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Surge Voltage Rated voltageB1.15V (at 105C)
Leakage Current Shall not exceed values shown in STANDARD RATINGS. (at 20C after 2 minutes)
Dissipation Factor
(tane) 0.12 max.
(at 20C, 120Hz)
Low Temperature
Characteristics Z(-25C)/Z(+20C)[1.15
(Max. Impedance Ratio) Z(-55C)/Z(+20C)[1.25
(at 100kHz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 2,000 hours
(F46 : 1,000 hours) at 105C.
Appearance No significant damage
Capacitance change [P20% of the initial value
DF (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Bias Humidity The following specifications shall be satisfied when the capacitors are restored to 20C after subjecting them to the DC rated voltage at
60C, 90 to 95% RH for 1,000 hours (F46 : 500hours).
Appearance No significant damage
Capacitance change [P20% of the initial value
DF (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Surge Voltage The capacitors shall be subjected to 1,000 cycles each consisting of charge with the surge voltage specified at 105C for 30 seconds
through a protective resistor(R=1kO) and discharge for 5 minutes 30 seconds.
Appearance No significant damage
Capacitance change [P20% of the initial value
DF (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Failure Rate 0.5% per 1,000 hours maximum (Confidence level 60% at 105C)
*Note : If any doubt arises, measure the leakage current after following voltage treatment.
Voltage treatment : DC rated voltage are applied to the capacitors for 120 minutes at 105C.
?DIMENSIONS [mm] ?MARKING
@Terminal Code : A EX) 2.5V330MF
W
K89A
330
FDP0.5
CP0.2
BP0.2
Size Code fD L A B C W P
P
E61 5 5.8 5.3 5.3 5.9 0.5 to 0.8 1.4 2.5V
F46 6.3 4.5 6.6 6.6 7.2 0.5 to 0.8 1.9
F61 6.3 5.8 6.6 6.6 7.2 0.5 to 0.8 1.9
0.3max. AP0.2
LP0.3 (Note)
Note : L+0.1/-0.2 for F46
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
A PXK AAA A RA AAA M AAA G
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 330MF:331, 560MF:561)
Taping code
Terminal code
Voltage code (ex. 2.5V:2R5, 6.3V:6R3)
Series code
Category
Please refer to "Product code guide (conductive polymer type)"
(1/2) CAT. No. E1001K
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Surface Mount
New!
?STANDARD RATINGS
WV Cap Size Leakage current ESR Rated ripple current
Part No.
(Vdc) (mF) code (mAmax/after 2min.) (momax/20c, 100k to 300kHz) (mArms/105c, 100kHz)
220 F46 300 19 2,780 APXK2R5ARA221MF46G
330 E61 412 16 3,500 APXK2R5ARA331ME61G
2.5
330 F46 700 16 3,500 APXK2R5ARA331MF46G
560 F61 700 16 3,500 APXK2R5ARA561MF61G
180 F46 360 19 2,780 APXK4R0ARA181MF46G
4 220 E61 440 17 3,390 APXK4R0ARA221ME61G
390 F61 780 17 3,390 APXK4R0ARA391MF61G
150 F46 472 19 2,780 APXK6R3ARA151MF46G
180 E61 567 17 3,390 APXK6R3ARA181ME61G
6.3
220 F46 700 18 3,200 APXK6R3ARA221MF46G
330 F61 1,040 17 3,390 APXK6R3ARA331MF61G
16 100 F61 320 24 2,490 APXK160ARA101MF61G
