Image preview - the first page of the document
>> Download psa documenatation <<
Text preview - extract from the document
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Radial Lead
PSC
Low profile
@Super low ESR, high temperature resistance and high ripple current capability Lower ESR
@Rated voltage range : 2.5 to 16Vdc
PSA
@Endurance : 2,000 hours at 105C
@Suitable for DC-DC converters, voltage regulators and decoupling applications Lower ESR
for computer motherboards
PS
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -55 to +105C
Rated Voltage Range 2.5 to 16Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Surge Voltage Rated voltageB1.15 (at 105C)
Leakage Current I=0.2CV
*Note Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (Vdc) (at 20C after 2 minutes)
Dissipation Factor
(tane) 0.08 max. (FA5 size : 0.12max.)
(at 20C, 120Hz)
Low Temperature Z(-25C)/Z(+20C)[1.15
Characteristics Z(-55C)/Z(+20C)[1.25
(Max. Impedance Ratio)
(at 100kHz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 2,000 hours
at 105C.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Bias Humidity Test The following specifications shall be satisfied when the capacitors are restored to 20C after subjecting them to DC voltage at 60C,
90 to 95% RH for 1,000 hours.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Surge Voltage Test The capacitors shall be subjected to 1,000 cycles each consisting of charge with the surge voltage specified at 105C for 30 seconds
through a protective resistor(R=1kO) and discharge for 5 minutes 30 seconds.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [150% of the initial specified value
ESR [150% of the initial specified value
Leakage current [The initial specified value
Failure Rate 0.5% per 1,000 hours maximum (Confidence level 60% at 105C)
*Note : If any doubt arises, measure the leakage current after the following voltage treatment.
Voltage treatment : DC rated voltage is applied to the capacitors for 120 minutes at 105C.
?DIMENSIONS [mm]
?MARKING
@Terminal Code : E EX) 4V560MF
Coated Case
FP0.5
FP0.5
A 292
Fd
FD+0.5max.
560
4V
(FA5) (HB5, JB5)
L' 15min. 4min. Size code FA5 HB5 JB5
fD 6.3 8.0 10.0
fd 0.5 0.8
F 2.5 3.5 5.0
fD' FD+0.5max
L' L+0.3max L+1.5max
(1/2) CAT. No. E1001K
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Radial Lead
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
A PSA AAA E AA AAA M AAA S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 270MF:271, 1,000MF:102)
