Image preview - the first page of the document
>> Download psf documenatation <<
Text preview - extract from the document
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Radial Lead
Upgrade!
@Super low ESR, high ripple current capability
PSF
@ESR 5mO max. (2 & 2.5Vdc)
@Longer life (5,000 hours at 105C)
@ESR after endurance is specified within the initial spec (2 & 2.5Vdc) Lower ESR
@Rated voltage range : 2 to 16Vdc PSE
@RoHS Compliant
@Halogen Free
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -55 to +105C
Rated Voltage Range 2 to 16Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Surge Voltage Rated voltage(V)B1.15 (at 105C)
Leakage Current I=0.2CV or 500MA, whichever is greater
*Note Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C after 2 minutes)
Dissipation Factor
(tane) 0.10 max.
(at 20C, 120Hz)
Low Temperature Z(-25C)/Z(+20C)[1.15
Characteristics Z(-55C)/Z(+20C)[1.25
(Max.Impedance Ratio)
(at 100kHz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 5,000 hours
at 105C.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [The initial specified value
ESR 2 & 2.5Vdc : [The initial specified value
16Vdc : [150% of the initial specified value
Leakage current [The initial specified value
Bias Humidity Test The following specifications shall be satisfied when the capacitors are restored to 20C after subjecting them to DC voltage at 60C,
90 to 95% RH for 1,000 hours.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [The initial specified value
ESR 2 & 2.5Vdc : [The initial specified value
16Vdc : [150% of the initial specified value
Leakage current [The initial specified value
Surge Voltage Test The capacitors shall be subjected to 1,000 cycles each consisting of charge with the surge voltage specified at 105C for 30 seconds
through a protective resistor(R=1kO) and discharge for 5 minutes 30 seconds.
Appearance No significant damage
Capacitance change [P20% of the initial value
D.F. (tanE) [The initial specified value
ESR 2 & 2.5Vdc : [The initial specified value
16Vdc : [150% of the initial specified value
Leakage current [The initial specified value
Failure Rate 0.5% per 1,000 hours maximum (Confidence level 60% at 105C)
*Note : If any doubt arises, measure the leakage current after the following voltage treatment.
Voltage treatment : DC rated voltage is applied to the capacitors for 120 minutes at 105C.
?DIMENSIONS [mm]
@Terminal Code : E
FP0.5
F05, F08, H08 Coated Case
Fd
Size code F05 F08 FA5 H08 HB5 JB5
fD 6.3 8.0 10.0
FD'
fd 0.45 0.6 0.5 0.6
F 2.5 3.5 5.0
fD' FD+0.5max.
(F05, F08, H08)
L' L+1.0max. L+0.3max. L+1.0max. L+1.5max.
L' 15min. 4min.
Coated Case ?MARKING
FP0.5
FA5, HB5, JB5
FP0.5
EX) 2.5V560MF
Fd
FD'
F 6D6
560
2.5V
(FA5) (HB5, JB5)
L' 15min. 4min.
(1/2) CAT. No. E1001K
CONDUCTIVE POLYMER ALUMINUM SOLID CAPACITORS Radial Lead
Upgrade!
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
A PS F 2 R 5 E AA 5 6 1 M F 0 8 S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 560MF:561)
