Image preview - the first page of the document
>> Download gxh documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS Long Life, 135C
New!
@For automobile modules and other high temperature applications Higher temperature
@Endurance with ripple current : 1,500 to 2,000 hours at 135C GXE GXH
@Solvent resistant type (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +135C
Rated Voltage Range 10 to 50Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.03CV or 4MA, whichever is greater.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C, 1 minute)
Dissipation Factor Rated voltage (Vdc) 10V 16V 25V 35V 50V
(tane) tanE (Max.) 0.20 0.16 0.14 0.12 0.10
When nominal capacitance exceeds 1,000MF, add 0.02 to the above value for each 1,000MF increase. (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 10V 16V 25V 35V 50V
Characteristics Z(-25C)/Z(+20C) 3 2 2 2 2
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 6 4 4 4 4 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for the specified time at 135C.
Time F10 : 1,500hours F12.5 & F16 : 2,000hours
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 135C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Coated Case
FP0.5
FP0.5
Fd
fD 10 12.5 16
fd 0.6 0.6 0.8
FD'
F 5.0 5.0 7.5
fD' FD+0.5max.
Vent L' 15min. 4min. (F10) (F12.5 & F16)
L' L+2.0max.
Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E GXH AAA E AA AAA M AAA H
Supplement code
Size code
?MARKING
Capacitance tolerance code
EX) 35V470MF
Capacitance code (ex. 330MF:331, 1,000MF:102)
