Image preview - the first page of the document
>> Download gxl documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS Longer life, 125C
GXL
@Long-Life version of GXE series
@For automobile modules and other high temperature applications Longer life
@Endurance with ripple current : 5,000 hours at 125C
GXE
@Solvent resistant type (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +125C
Rated Voltage Range 10 to 50Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.03CV or 4MA, whichever is greater.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C, 1 minute)
Dissipation Factor Rated voltage (Vdc) 10V 16V 25V 35V 50V
(tane) tanE (Max.) 0.20 0.16 0.14 0.12 0.10 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 10V 16V 25V 35V 50V
Characteristics Z(-25C)/Z(+20C) 3 2 2 2 2
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 6 4 4 4 4 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 5,000 hours at 125C.
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 125C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P30% of the initial value
D.F. (tanE) [300% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Orange)
FP0.5
Fd
fD 10
FD'
fd 0.6
F 5.0
Vent L' 15min. 4min. fD' FD+0.5max.
(F10) L' L+1.5max.
Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E GX L AAA E AA AAA M AAA S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 100MF:101, 1,000MF:102)
Lead forming◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
