Image preview - the first page of the document
>> Download kme_bipolar documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS Bi-polar, 105C
@Standard Bi-polar type
@Endurance : 1,000 hours at 105C
@Solvent resistant type (see PRECAUTIONS AND GUIDELINES)
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -55 to +105C
Rated Voltage Range 6.3 to 100Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.06CV or 10MA, whichever is greater. (at 20C after 2 minutes)
I=0.03CV or 3MA, whichever is greater. (at 20C after 5 minutes)
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
Dissipation Factor Rated voltage (Vdc) 6.3V 10V 16V 25V 35V 50V 63V 80V 100V
(tane) tanE (Max.) 0.24 0.24 0.20 0.20 0.16 0.14 0.12 0.12 0.10
When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase. (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 6.3V 10V 16V 25V 35V 50V 63V 80V 100V
Characteristics Z(-25C)/Z(+20C) 4 3 2 2 2 2 2 2 2
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 10 8 6 4 3 3 3 3 3 (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for 1,000 hours
at 105C, however the polarization shall be reversed every 250 hours.
Rated voltage 6.3 to 16Vdc 25 to 100Vdc
Capacitance change [P25% of the initial value [P20% of the initial value
D.F. (tanE) [150% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 500 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Rated voltage 6.3 to 16Vdc 25 to 100Vdc
Capacitance change [P25% of the initial value [P20% of the initial value
D.F. (tanE) [150% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Brown)
FP0.5
FP0.5
Fd
fD 5 6.3 8 10 12.5 16 18
fd 0.5 0.5 0.6 0.6 0.6 0.8 0.8
FD'
F 2.0 2.5 3.5 5.0 5.0 7.5 7.5
fD' FD+0.5max.
L' 15min. 4min. L' L+1.5max.
(F5 to F10) (F12.5 to F18)
Vent
(except F5) Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
B KME A A A E A A A A A M A A A N
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 1.0MF:1R0,10MF:100,100MF:101)
Lead forming◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
