Image preview - the first page of the document
kmg


>> Download kmg documenatation <<

Text preview - extract from the document
                               MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS                                                                             Standard, Downsized, 105C




                                                                                                                                KMQ
@Endurance with ripple current : 1,000 to 2,000 hours at 105C                                                                            Downsized
@Solvent resistant type except 350 to 450Vdc
  (see PRECAUTIONS AND GUIDELINES)                                                                                            KMG
@RoHS Compliant

?SPECIFICATIONS
              Items                                                                                                   Characteristics
Category
Temperature Range                      -55 to +105C(6.3 to 100Vdc) -40 to +105C(160 to 400Vdc) -25 to +105C(450Vdc)

Rated Voltage Range                    6.3 to 450Vdc
Capacitance Tolerance                  P20% (M)                                                                                                                               (at 20C, 120Hz)
Leakage Current                        6.3 to 100Vdc                                                                            160 to 450Vdc
                                       I=0.03CV or 4MA, whichever is greater.                                                   CV     Time After 1minute              After 5minutes
                                                                                                                                CV[1,000 I=0.1CV+40 max.               I=0.03CV+15 max.
                                                                                                                                CV>1,000 I=0.04CV+100 max.             I=0.02CV+25 max.
                                                                                        (at 20C after 1 minute)                                                                       (at 20C)
                                       Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
Dissipation Factor                     Rated voltage (Vdc)           6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 350 to 400V 450V
(tane)                                 tanE (Max.)                   0.34 0.24 0.20 0.16 0.14 0.12 0.10 0.08                       0.20          0.24       0.24
                                       When nominal capacitance exceeds 1,000MF, add 0.02 to the value above for each 1,000MF increase.                                  (at 20C, 120Hz)
Low Temperature                        Rated voltage (Vdc)           6.3V 10V 16V 25V 35V 50V 63V 100V 160 to 250V 350 to 400V 450V
Characteristics                        Z(-25C)/Z(+20C)                 5      4      3       2     2        2      2      2          3             6          6
(Max. Impedance Ratio)
                                       Z(-40C)/Z(+20C)                12     10      8       5     4        3      3      3          4             6          -                (at 120Hz)
Endurance                              The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
                                       ripple current is applied for 1,000 hours (2,000 hours to meet the following two conditions 1) : 160Vdc and larger, 2) : F12.5 and larger) at 105C.
                                       Capacitance change            [P20% of the initial value
                                       D.F. (tanE)                   [200% of the initial specified value
                                       Leakage current               [The initial specified value
Shelf Life                             The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
                                       voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
                                       Rated voltage                 6.3 to 100Vdc                           160 to 450Vdc
                                       Capacitance change            [P20% of the initial value              [P20% of the initial value
                                       D.F. (tanE)                   [200% of the initial specified value [200% of the initial specified value
                                       Leakage current               [The initial specified value            [500% of the initial specified value


?DIMENSIONS [mm]
@Terminal Code : E
          Sleeve (PET : Brown)
                                                                                                                                 FP0.5
                                                                                                          FP0.5
                                                           Fd




                                                                                                                                                     fD     5    6.3    8    10 12.5   16    18
                                                                                                                                                           0.5   0.5   0.6 0.6 0.6     0.8   0.8
FD'




                                                                                                                                                     fd
                                                                                                                                                      F    2.0   2.5   3.5 5.0 5.0     7.5   7.5
                                                                                                                                                     fD'                FD+0.5max.
                          L'                          15min.                        4min.                                                             L'                  L+1.5max
                                                                                            (F5 to F10)              (F12.5 to F18)
 Vent                                                                                              Gas escape end seal
 (except F5)


?PART NUMBERING SYSTEM
      1   2   3   4   5   6    7   8    9   10   11   12   13   14   15   16   17    18

  E KMG A A A E A A A A A M A A A N
                                                                                                               Supplement code
                                                                                                                       Size code
                                                                                                     Capacitance tolerance code
                                                                          Capacitance code (ex. 1.0MF:1R0,10MF:100,100MF:101)
                                                                                                        Lead forming
