Image preview - the first page of the document
>> Download kms_snapin documenatation <<
Text preview - extract from the document
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Downsized snap-ins, 105C
LXS
@For solar power generation Longer life
@Endurance with ripple current : 105C 3,000 hours KMS
@Rated voltage range : 160 to 500V
@Capacitance range : 47 to 3,300MF Downsized
@Non solvent resistant type Higher ripple
KMM
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -25 to +105C
Rated Voltage Range 160 to 500Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I[3 CV
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C after 5 minutes)
Dissipation Factor Rated voltage (Vdc) 160 to 400V 420 to 500V
(tane) tanE (Max.) 0.15 0.20 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 160 to 400V 420 to 500V
Characteristics Z(-25C)/Z(+20C) 4 8
(Max. Impedance Ratio)
(at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 3,000 hours at 105C.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P15% of the initial value
D.F. (tanE) [150% of the initial specified value
Leakage current [The initial specified value
?DIMENSIONS [mm]
@Terminal Code : VS (F22 to F35) : Standard @Terminal Code : LI (F35)
Sleeve (PET : Brown) Negative mark PC board pin-out Sleeve (PET : Brown) Negative mark PC board pin-out
4.2P0.5
2-1.2B6
10
FD+1max.
FD+1max.
5P0.5
2-F2
LP2.5 4.0P0.5 LP2.5 4.5P1 14.2P1
Vent Vent
The standard design has no plastic disc.
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E KMS A A A V S N A A A M A A A S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 100MF:101, 1,000MF:102)
Dummy terminal code
Terminal code (VS, LI)
Voltage code (ex. 160V:161, 400V:401)
Series code
Category
Please refer to "Product code guide (snap-in type)"
(1/3) CAT. No. E1001K
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Downsized snap-ins, 105C
?STANDARD RATINGS
Rated ripple Rated ripple
WV Cap Case size current WV Cap Case size current
tane Part No. tane Part No.
(Vdc) (mF) fDbL(mm) (Arms/ (Vdc) (mF) fDbL(mm) (Arms/
105c,120Hz) 105c,120Hz)
470 22 B 25 0.15 1.47 EKMS161VSN471MP25S 1,800 30 B 45 0.15 3.66 EKMS201VSN182MR45S
680 22 B 30 0.15 1.86 EKMS161VSN681MP30S 1,800 30 B 50 0.15 3.72 EKMS201VSN182MR50S
680 25.4 B 25 0.15 1.84 EKMS161VSN681MQ25S 200 1,800 35 B 40 0.15 3.81 EKMS201VSN182MA40S
820 22 B 35 0.15 2.09 EKMS161VSN821MP35S 2,200 35 B 45 0.15 4.32 EKMS201VSN222MA45S
820 25.4 B 30 0.15 2.08 EKMS161VSN821MQ30S 2,700 35 B 50 0.15 4.88 EKMS201VSN272MA50S
1,000 22 B 40 0.15 2.35 EKMS161VSN102MP40S 270 22 B 25 0.15 1.11 EKMS251VSN271MP25S
1,000 22 B 45 0.15 2.40 EKMS161VSN102MP45S 330 22 B 30 0.15 1.29 EKMS251VSN331MP30S
1,000 25.4 B 35 0.15 2.40 EKMS161VSN102MQ35S 390 22 B 35 0.15 1.44 EKMS251VSN391MP35S
1,000 30 B 25 0.15 2.50 EKMS161VSN102MR25S 390 25.4 B 25 0.15 1.40 EKMS251VSN391MQ25S
1,200 22 B 50 0.15 2.69 EKMS161VSN122MP50S 470 22 B 40 0.15 1.61 EKMS251VSN471MP40S
1,200 25.4 B 40 0.15 2.68 EKMS161VSN122MQ40S 470 25.4 B 30 0.15 1.57 EKMS251VSN471MQ30S
1,200 30 B 30 0.15 2.77 EKMS161VSN122MR30S 560 22 B 45 0.15 1.79 EKMS251VSN561MP45S
160
1,200 35 B 25 0.15 2.91 EKMS161VSN122MA25S 560 25.4 B 35 0.15 1.79 EKMS251VSN561MQ35S
1,500 25.4 B 45 0.15 3.05 EKMS161VSN152MQ45S 560 30 B 25 0.15 1.87 EKMS251VSN561MR25S
1,500 30 B 35 0.15 3.17 EKMS161VSN152MR35S 680 22 B 50 0.15 2.02 EKMS251VSN681MP50S
1,800 25.4 B 50 0.15 3.40 EKMS161VSN182MQ50S 680 25.4 B 40 0.15 2.02 EKMS251VSN681MQ40S
1,800 30 B 40 0.15 3.57 EKMS161VSN182MR40S 680 30 B 30 0.15 2.08 EKMS251VSN681MR30S
250
1,800 35 B 30 0.15 3.62 EKMS161VSN182MA30S 680 35 B 25 0.15 2.19 EKMS251VSN681MA25S
2,200 30 B 45 0.15 4.05 EKMS161VSN222MR45S 820 25.4 B 45 0.15 2.26 EKMS251VSN821MQ45S
2,200 35 B 35 0.15 4.07 EKMS161VSN222MA35S 820 30 B 35 0.15 2.34 EKMS251VSN821MR35S
2,700 30 B 50 0.15 4.56 EKMS161VSN272MR50S 1,000 25.4 B 50 0.15 2.53 EKMS251VSN102MQ50S
2,700 35 B 40 0.15 4.67 EKMS161VSN272MA40S 1,000 30 B 40 0.15 2.66 EKMS251VSN102MR40S
2,700 35 B 45 0.15 4.78 EKMS161VSN272MA45S 1,000 35 B 30 0.15 2.70 EKMS251VSN102MA30S
3,300 35 B 50 0.15 5.40 EKMS161VSN332MA50S 1,200 30 B 45 0.15 2.99 EKMS251VSN122MR45S
390 22 B 25 0.15 1.34 EKMS181VSN391MP25S 1,200 30 B 50 0.15 3.04 EKMS251VSN122MR50S
560 22 B 30 0.15 1.68 EKMS181VSN561MP30S 1,200 35 B 35 0.15 3.00 EKMS251VSN122MA35S
560 25.4 B 25 0.15 1.67 EKMS181VSN561MQ25S 1,500 35 B 40 0.15 3.48 EKMS251VSN152MA40S
680 22 B 35 0.15 1.90 EKMS181VSN681MP35S 1,500 35 B 45 0.15 3.56 EKMS251VSN152MA45S
820 22 B 40 0.15 2.13 EKMS181VSN821MP40S 1,800 35 B 50 0.15 3.98 EKMS251VSN182MA50S
820 25.4 B 30 0.15 2.08 EKMS181VSN821MQ30S 180 22 B 25 0.15 0.95 EKMS3B1VSN181MP25S
820 30 B 25 0.15 2.26 EKMS181VSN821MR25S 220 22 B 30 0.15 1.10 EKMS3B1VSN221MP30S
1,000 22 B 45 0.15 2.40 EKMS181VSN102MP45S 220 25.4 B 25 0.15 1.10 EKMS3B1VSN221MQ25S
1,000 22 B 50 0.15 2.45 EKMS181VSN102MP50S 270 22 B 35 0.15 1.24 EKMS3B1VSN271MP35S
1,000 25.4 B 35 0.15 2.40 EKMS181VSN102MQ35S 330 22 B 40 0.15 1.40 EKMS3B1VSN331MP40S
1,000 25.4 B 40 0.15 2.45 EKMS181VSN102MQ40S 330 25.4 B 30 0.15 1.38 EKMS3B1VSN331MQ30S
1,000 30 B 30 0.15 2.52 EKMS181VSN102MR30S 330 30 B 25 0.15 1.43 EKMS3B1VSN331MR25S
180
1,200 25.4 B 45 0.15 2.73 EKMS181VSN122MQ45S 390 22 B 45 0.15 1.56 EKMS3B1VSN391MP45S
1,200 30 B 35 0.15 2.83 EKMS181VSN122MR35S 390 22 B 50 0.15 1.59 EKMS3B1VSN391MP50S
1,200 35 B 25 0.15 2.91 EKMS181VSN122MA25S 390 25.4 B 35 0.15 1.57 EKMS3B1VSN391MQ35S
1,500 25.4 B 50 0.15 3.10 EKMS181VSN152MQ50S 470 25.4 B 40 0.15 1.76 EKMS3B1VSN471MQ40S
1,500 30 B 40 0.15 3.26 EKMS181VSN152MR40S 470 30 B 30 0.15 1.73 EKMS3B1VSN471MR30S
315
1,500 35 B 30 0.15 3.31 EKMS181VSN152MA30S 470 35 B 25 0.15 1.82 EKMS3B1VSN471MA25S
1,800 30 B 45 0.15 3.66 EKMS181VSN182MR45S 560 25.4 B 45 0.15 1.96 EKMS3B1VSN561MQ45S
1,800 35 B 35 0.15 3.68 EKMS181VSN182MA35S 560 25.4 B 50 0.15 1.99 EKMS3B1VSN561MQ50S
2,200 30 B 50 0.15 4.11 EKMS181VSN222MR50S 560 30 B 35 0.15 1.93 EKMS3B1VSN561MR35S
2,200 35 B 40 0.15 4.22 EKMS181VSN222MA40S 560 35 B 30 0.15 2.02 EKMS3B1VSN561MA30S
2,700 35 B 45 0.15 4.78 EKMS181VSN272MA45S 680 30 B 40 0.15 2.19 EKMS3B1VSN681MR40S
2,700 35 B 50 0.15 4.88 EKMS181VSN272MA50S 680 35 B 35 0.15 2.26 EKMS3B1VSN681MA35S
390 22 B 25 0.15 1.34 EKMS201VSN391MP25S 820 30 B 45 0.15 2.47 EKMS3B1VSN821MR45S
470 22 B 30 0.15 1.54 EKMS201VSN471MP30S 820 30 B 50 0.15 2.51 EKMS3B1VSN821MR50S
560 22 B 35 0.15 1.72 EKMS201VSN561MP35S 820 35 B 40 0.15 2.57 EKMS3B1VSN821MA40S
560 25.4 B 25 0.15 1.67 EKMS201VSN561MQ25S 1,000 35 B 45 0.15 2.91 EKMS3B1VSN102MA45S
680 22 B 40 0.15 1.94 EKMS201VSN681MP40S 1,200 35 B 50 0.15 3.25 EKMS3B1VSN122MA50S
680 25.4 B 30 0.15 1.89 EKMS201VSN681MQ30S 120 22 B 25 0.15 0.77 EKMS401VSN121MP25S
820 22 B 45 0.15 2.17 EKMS201VSN821MP45S 150 22 B 30 0.15 0.90 EKMS401VSN151MP30S
820 25.4 B 35 0.15 2.17 EKMS201VSN821MQ35S 180 22 B 35 0.15 1.02 EKMS401VSN181MP35S
820 30 B 25 0.15 2.26 EKMS201VSN821MR25S 180 25.4 B 25 0.15 0.99 EKMS401VSN181MQ25S
200 1,000 22 B 50 0.15 2.45 EKMS201VSN102MP50S 220 22 B 40 0.15 1.15 EKMS401VSN221MP40S
1,000 25.4 B 40 0.15 2.45 EKMS201VSN102MQ40S 220 25.4 B 30 0.15 1.13 EKMS401VSN221MQ30S
1,000 30 B 30 0.15 2.52 EKMS201VSN102MR30S 270 22 B 45 0.15 1.29 EKMS401VSN271MP45S
400
1,000 35 B 25 0.15 2.66 EKMS201VSN102MA25S 270 25.4 B 35 0.15 1.30 EKMS401VSN271MQ35S
1,200 25.4 B 45 0.15 2.73 EKMS201VSN122MQ45S 270 30 B 25 0.15 1.29 EKMS401VSN271MR25S
1,200 25.4 B 50 0.15 2.78 EKMS201VSN122MQ50S 330 22 B 50 0.15 1.47 EKMS401VSN331MP50S
1,200 30 B 35 0.15 2.83 EKMS201VSN122MR35S 330 25.4 B 40 0.15 1.47 EKMS401VSN331MQ40S
1,200 35 B 30 0.15 2.96 EKMS201VSN122MA30S 330 30 B 30 0.15 1.45 EKMS401VSN331MR30S
1,500 30 B 40 0.15 3.26 EKMS201VSN152MR40S 330 35 B 25 0.15 1.52 EKMS401VSN331MA25S
1,500 35 B 35 0.15 3.36 EKMS201VSN152MA35S 390 25.4 B 45 0.15 1.63 EKMS401VSN391MQ45S
(2/3) CAT. No. E1001K
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS Downsized snap-ins, 105C
?STANDARD RATINGS
Rated ripple Rated ripple
WV Cap Case size current WV Cap Case size current
tane Part No. tane Part No.
(Vdc) (mF) fDbL(mm) (Arms/ (Vdc) (mF) fDbL(mm) (Arms/
105c,120Hz) 105c,120Hz)
390 25.4 B 50 0.15 1.66 EKMS401VSN391MQ50S 180 25.4 B 35 0.20 1.06 EKMS451VSN181MQ35S
390 30 B 35 0.15 1.61 EKMS401VSN391MR35S 180 30 B 25 0.20 1.06 EKMS451VSN181MR25S
470 30 B 40 0.15 1.82 EKMS401VSN471MR40S 220 22 B 50 0.20 1.20 EKMS451VSN221MP50S
470 35 B 30 0.15 1.85 EKMS401VSN471MA30S 220 25.4 B 40 0.20 1.20 EKMS451VSN221MQ40S
560 30 B 45 0.15 2.04 EKMS401VSN561MR45S 220 30 B 30 0.20 1.18 EKMS451VSN221MR30S
400
560 30 B 50 0.15 2.07 EKMS401VSN561MR50S 220 35 B 25 0.20 1.24 EKMS451VSN221MA25S
560 35 B 35 0.15 2.05 EKMS401VSN561MA35S 270 25.4 B 45 0.20 1.36 EKMS451VSN271MQ45S
680 35 B 40 0.15 2.34 EKMS401VSN681MA40S 270 25.4 B 50 0.20 1.38 EKMS451VSN271MQ50S
680 35 B 45 0.15 2.40 EKMS401VSN681MA45S 450 270 30 B 35 0.20 1.34 EKMS451VSN271MR35S
820 35 B 50 0.15 2.69 EKMS401VSN821MA50S 270 35 B 30 0.20 1.40 EKMS451VSN271MA30S
100 22 B 25 0.20 0.70 EKMS421VSN101MP25S 330 30 B 40 0.20 1.52 EKMS451VSN331MR40S
120 22 B 30 0.20 0.81 EKMS421VSN121MP30S 390 30 B 45 0.20 1.70 EKMS451VSN391MR45S
120 25.4 B 25 0.20 0.81 EKMS421VSN121MQ25S 390 30 B 50 0.20 1.73 EKMS451VSN391MR50S
150 22 B 35 0.20 0.93 EKMS421VSN151MP35S 390 35 B 35 0.20 1.71 EKMS451VSN391MA35S
180 22 B 40 0.20 1.04 EKMS421VSN181MP40S 470 35 B 40 0.20 1.95 EKMS451VSN471MA40S
180 25.4 B 30 0.20 1.02 EKMS421VSN181MQ30S 470 35 B 45 0.20 1.99 EKMS451VSN471MA45S
180 30 B 25 0.20 1.06 EKMS421VSN181MR25S 560 35 B 50 0.20 2.22 EKMS451VSN561MA50S
220 22 B 45 0.20 1.17 EKMS421VSN221MP45S 47 22B25 0.20 0.51 EKMS501VSN470MP25S
220 22 B 50 0.20 1.20 EKMS421VSN221MP50S 56 22B30 0.20 0.58 EKMS501VSN560MP30S
220 25.4 B 35 0.20 1.18 EKMS421VSN221MQ35S 68 25.4B25 0.20 0.65 EKMS501VSN680MQ25S
220 30 B 30 0.20 1.18 EKMS421VSN221MR30S 82 22B35 0.20 0.72 EKMS501VSN820MP35S
270 25.4 B 40 0.20 1.33 EKMS421VSN271MQ40S 82 25.4B30 0.20 0.74 EKMS501VSN820MQ30S
420
270 25.4 B 45 0.20 1.36 EKMS421VSN271MQ45S 100 22B45 0.20 0.83 EKMS501VSN101MP45S
270 35 B 25 0.20 1.38 EKMS421VSN271MA25S 100 30B25 0.20 0.82 EKMS501VSN101MR25S
330 25.4 B 50 0.20 1.52 EKMS421VSN331MQ50S 120 22B50 0.20 0.93 EKMS501VSN121MP50S
330 30 B 35 0.20 1.48 EKMS421VSN331MR35S 120 25.4B35 0.20 0.93 EKMS501VSN121MQ35S
330 30 B 40 0.20 1.52 EKMS421VSN331MR40S 120 30B30 0.20 0.91 EKMS501VSN121MR30S
330 35 B 30 0.20 1.55 EKMS421VSN331MA30S 150 25.4B45 0.20 1.08 EKMS501VSN151MQ45S
390 30 B 45 0.20 1.70 EKMS421VSN391MR45S 500 150 30B35 0.20 1.04 EKMS501VSN151MR35S
390 35 B 35 0.20 1.71 EKMS421VSN391MA35S 150 35B25 0.20 0.99 EKMS501VSN151MA25S
470 30 B 50 0.20 1.90 EKMS421VSN471MR50S 180 25.4B50 0.20 1.20 EKMS501VSN181MQ50S
470 35 B 40 0.20 1.95 EKMS421VSN471MA40S 180 30B40 0.20 1.17 EKMS501VSN181MR40S
560 35 B 45 0.20 2.17 EKMS421VSN561MA45S 180 35B30 0.20 1.10 EKMS501VSN181MA30S
680 35 B 50 0.20 2.45 EKMS421VSN681MA50S 220 30B45 0.20 1.33 EKMS501VSN221MR45S
82 22 B 25 0.20 0.64 EKMS451VSN820MP25S 220 35B35 0.20 1.23 EKMS501VSN221MA35S
120 22 B 30 0.20 0.81 EKMS451VSN121MP30S 270 30B50 0.20 1.50 EKMS501VSN271MR50S
120 22 B 35 0.20 0.83 EKMS451VSN121MP35S 270 35B40 0.20 1.42 EKMS501VSN271MA40S
450 120 25.4 B 25 0.20 0.81 EKMS451VSN121MQ25S 330 35B45 0.20 1.60 EKMS501VSN331MA45S
150 22 B 40 0.20 0.94 EKMS451VSN151MP40S 390 35B50 0.20 1.78 EKMS501VSN391MA50S
150 25.4 B 30 0.20 0.93 EKMS451VSN151MQ30S 470 35B60 0.20 2.03 EKMS501VSN471MA60S
180 22 B 45 0.20 1.06 EKMS451VSN181MP45S
?RATED RIPPLE CURRENT MULTIPLIERS
@Frequency Multipliers
Frequency(Hz) 50 120 300 1k 10k 50k
160 to 250Vdc 0.81 1.00 1.17 1.32 1.45 1.50 The endurance of capacitors is reduced with internal heating produced by ripple
current at the rate of halving the lifetime with every 5C rise.
315 to 450Vdc 0.77 1.00 1.16 1.30 1.41 1.43
When long life performance is required in actual use, the rms ripple current has
500Vdc 0.70 1.00 1.16 1.30 1.41 1.43 to be reduced.
(3/3) CAT. No. E1001K
