Image preview - the first page of the document
>> Download klj documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS Overvoltage resistant design, 105C
KLJ
@Doesn't spark with DC over voltage
@Endurance with ripple current : 2,000 hours at 105C Downsized
@Non solvent resistant type
@ESR value prescribed KLG
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -25 to +105C
Rated Voltage Range 200 & 400Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current I=0.04CV+100
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C after 1 minute)
Dissipation Factor Rated voltage (Vdc) 200V 400V
(tane) tanE (Max.) 0.20 0.24 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 200V 400V
Characteristics Z(-25C)/Z(+20C) 4 6
(Max. Impedance Ratio)
(at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 2,000 hours at 105C.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [500% of the initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Brown)
FP0.5
FP0.5
Fd
fD 10 12.5 16 18
FD'
fd 0.6 0.6 0.8 0.8
F 5.0 5.0 7.5 7.5
L' 15min. 4min. fD' FD+0.5max.
(F10) (F12.5 to F18)
L' L+1.5max.
Vent Gas escape end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E KL J 2 0 1 E LL 1 0 1 M L 2 0 S
Supplement code (sleeve PET:S, Pb-free PVC:M)
Size code
Capacitance tolerance code
Capacitance code (ex. 100MF:101,4.7MF:4R7)
Lead forming◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
