Image preview - the first page of the document
>> Download kxj documenatation <<
Text preview - extract from the document
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS 160 to 450Vdc long life, 105C
KXJ
@Downsized and Longer life from current KXG series
@Endurance with ripple current : 10,000 to 12,000 hours at 105C Downsized
@Rated voltage range : 160 to 450V, Capacitance range : 6.8 to 680MF
@For electronic ballast circuits and other long life applications KXG
@Non solvent resistant type
@RoHS Compliant
?SPECIFICATIONS
Items Characteristics
Category
Temperature Range -40 to +105C (160 to 400Vdc) -25 to +105C (420, 450Vdc)
Rated Voltage Range 160 to 450Vdc
Capacitance Tolerance P20% (M) (at 20C, 120Hz)
Leakage Current After 1 minute After 5 minutes
CV[1000 I=0.1CV+40 I=0.03CV+15
CV>1000 I=0.04CV+100 I=0.02CV+25
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V) (at 20C)
Dissipation Factor Rated voltage (Vdc) 160 to 250V 350 to 450V
(tanE) tanE (Max.) 0.20 0.24 (at 20C, 120Hz)
Low Temperature Rated voltage (Vdc) 160 to 250V 350, 400V 420, 450V
Characteristics Z(-25C)/Z(+20C) 3 5 6
(Max. Impedance Ratio)
Z(-40C)/Z(+20C) 6 6 - (at 120Hz)
Endurance The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 12,000 hours (10,000 hours for 20L max.) at 105C.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [The initial specified value
Shelf Life The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1,000 hours at 105C without
voltage applied. Before the measurement, the capacitor shall be preconditioned by applying voltage according to Item 4.1 of JIS C 5101-4.
Capacitance change [P20% of the initial value
D.F. (tanE) [200% of the initial specified value
Leakage current [500% of the initial specified value
?DIMENSIONS [mm]
@Terminal Code : E
Sleeve (PET : Brown)
FP0.5
FP0.5
Fd
fD 10 12.5 14.5 16 18
fd 0.6 0.6 0.8 0.8 0.8
FD'
F 5.0 5.0 7.5 7.5 7.5
fD' FD+0.5max.
Vent L' 15min. 4min. (F10) (F12.5 to F18) L' L+1.5max.
Gas escaped end seal
?PART NUMBERING SYSTEM
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
E KX J AAA E AA AAA M AAA S
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 6.8MF:6R8,10MF:100,100MF:101)
